| Professional high-speed vertical burger bun toaster |
CTVGV |
| Ideal for |
Burger restaurants, fast food outlets, snack bars, restaurants, brasseries, hotels, buffets, food courts, food trucks, dark kitchens and professional kitchens. |
| EAN code |
3611630080248 |
| Overall size |
Cm 67.5 x 27.8 x 57 h |
| Weight |
27.35 kg |
| Warranty |
12 months |
| Compliance |
CE |
| Origin |
France |
| TECHNICAL SPECIFICATIONS |
| Housing |
Stainless steel |
| Installation |
Countertop, with vertical bread feed |
| Control |
ON/OFF switch |
| Conveyor |
Adjustable conveyor belt speed |
| Bread lanes |
Dedicated paths for burger bun crowns and heels |
| Stated toasting time |
8 seconds |
| Stated output |
3600 toasted bread portions/hour, equivalent to both halves of 1800 burger buns |
| Thickness adjustment |
2 independent knobs to adapt the passage to bread thickness |
| Thermostat |
Adjustable from 60 to 300 °C |
| Included accessories |
2 cooking sheets |
| Compatible accessories |
Cooking sheet, bun insert and heated butter wheel. References listed by the manufacturer: CFCTV, CIBTV600, CRBC or CRBCTV600. |
| Power |
2200 W |
| Power supply |
230 V – 50/60 Hz |
| MAIN FEATURES |
| The CTVGV vertical toaster is designed for the continuous preparation of warm, toasted bread on the burger line. It combines adjustable conveying, temperature control and thickness adjustment in a countertop station dedicated to toasting before assembly. |
| The stated toasting time of 8 seconds and stated output of 3600 toasted bread portions per hour, equivalent to both halves of 1800 burger buns, help organise bread preparation during busy service periods. |
| Conveyor belt speed can be adjusted to suit the bread and desired toasting level. The thermostat, adjustable from 60 to 300 °C, allows heat to be adapted to different products and the required degree of browning. |
| Dedicated lanes for the top and bottom of the bun facilitate the separate passage of crowns and heels. The 2 independent knobs allow the passage to be adapted to bread thickness and different formats. |
| The stainless steel housing suits professional environments and facilitates external cleaning after service. The 2 included cooking sheets accompany the passage of the bread; compatible accessories allow the station to be adapted to production requirements. |
| APPLICATIONS |
| Suitable for toasting burger buns, bagels and bread for sandwiches and hot rolls, with passage and temperature settings adapted to the product used. |
| In burger restaurants, fast food outlets and snack bars, it supports bread preparation during peak ordering periods. In restaurants and brasseries, it provides a dedicated station for the hot food line; in hotels and buffets, it organises toasting according to service requirements. It also integrates into food courts, food trucks and dark kitchens requiring an orderly preparation workflow. |
| INSTALLATION AND SERVICE ORGANISATION |
| Place the toaster near the burger preparation area to reduce movement and improve the flow of assembly. Adjust thickness using the 2 independent knobs, select the temperature and adapt conveyor speed to the bread used. |
| Insert the bun crown and heel into their dedicated lanes. Position the toasted bread outlet close to the assembly area to coordinate buns, meat and garnishes and maintain a regular working sequence. |
| ORGANISATION AND CLEANING |
| The ON/OFF switch and accessible adjustments facilitate daily operation. Clean the stainless steel housing and handle the cooking sheets according to the manufacturer's instructions, keeping the bread inlet and outlet areas organised. |
