| Ice Maker | model SVH303AS |
| Cube type | says |
| Dimensions cube | mm 22 x 22 x 22 h |
| Cube grams | 10 g |
| Production kg - 24 h air condensation | Kg 290 |
| External bin | Optional (to be chosen) |
| Condensation | Air |
| Warranty | 12 months |
| Standard | CE |
| Origin | Italy |
| PRODUCT DIMENSIONS | |
|---|---|
| Dimensions machines | Cm 76 x 62 x 57.5 h |
| Dimensions packaging | Cm 83 x 69 x 72 h |
| Net weight - Gross weight | Kg 72 - 88 |
| Volume | M³ 0.41 |
| VOLTAGE E CONSUMPTION | |
|---|---|
| Power supply | Monophase V230-50-1 Hz |
| Available on request | V 220-60-1 |
| Air consumption | W 1050 |
| OPERATING LIMITS | |
|---|---|
| Temperature air | Minimum 10°C - Maximum 40°C |
| Electrical voltage | Minimum -10% Maximum +10% |
| GENERAL CHARACTERISTICS | |
|---|---|
| High efficiency vertical evaporator | |
| Stainless steel construction | |
| Revealed water and electric savings | |
| Self-diagnostic system with led indicators | |
| Easily removable condenser filter | |
| Front access to evaporator: immediate access to evaporator for quick cleaning operations | |
| Modular maker: requires a separate container to collect the ice produced | |
| Refrigerant GAS R 290 |
| RECOMMENDED CONTAINERS | |
|---|---|
| R150 | 181 kg |
| R190 | Kg 243 |
| CONTAINERS REQUIRING LIDS | |
|---|---|
| R300 | Kg 406 |
- *HOURLY PRODUCTION
- *fino a 400 kg/ 24 h*
- *ICE CONTAINER
- *Prepared for external container*
