Full cube ice maker - Air 210 kg/24h
S-MGG-SVH222AS
S-MGG-SVH222AS
€2,410.40
€2,620.00
-8%
€2,410.40 Senza tasse
€2,940.69 Con tasse
€2,620.00 Senza tasse
Tax excluded
Full cube ice maker - Model SVH222AS - Production with air motor kg 250/24h - Dimensions cm 55.8 x 61 x 60.9 h
Options
+ ACCESSORIES
| Ice Maker | model SVH222AS |
| Cube type | says |
| Dimensions cube | mm 22 x 22 x 22 h |
| Cube grams | 10 g |
| Production kg - 24 h air condensation | Kg 210 |
| External bin | Optional (to be chosen) |
| Condensation | Air |
| Warranty | 12 months |
| Standard | CE |
| Origin | Italy |
| PRODUCT DIMENSIONS | |
|---|---|
| Dimensions machines | Cm 55.8 x 61 x 60.9 h |
| Dimensions packaging | Cm 62 x 68 x 80 h |
| Net weight - Gross weight | Kg 65 - 80 |
| Volume | M³ 0.34 |
| VOLTAGE E CONSUMPTION | |
|---|---|
| Power supply | Monophase V230-50-1 Hz |
| Available on request | V 220-60-1 |
| Air consumption | W 1000 |
| OPERATING LIMITS | |
|---|---|
| Temperature air | Minimum 10°C - Maximum 40°C |
| Electrical voltage | Minimum -10% Maximum +10% |
| GENERAL CHARACTERISTICS | |
|---|---|
| High efficiency vertical evaporator | |
| Stainless steel construction | |
| Revealed water and electric savings | |
| Self-diagnostic system with led indicators | |
| Easily removable condenser filter | |
| Front access to evaporator: immediate access to evaporator for quick cleaning operations | |
| Modular maker: requires a separate container to collect the ice produced | |
| Refrigerant GAS R 290 |
| RECOMMENDED CONTAINERS | |
|---|---|
| R100 | 129 kg |
| R130 | Kg 168 |
| CONTAINERS REQUIRING LIDS | |
|---|---|
| R150 | Kg 181 |
| R190 | Kg 243 |
- *HOURLY PRODUCTION
- *fino a 300 kg/ 24 h*
- *ICE CONTAINER
- *Prepared for external container*
